General| Battery type | Lithium - Ion |
|---|---|
| Power source | Battery |
| Charging time | 1 h |
| Battery voltage | 40 V |
| Battery capacity | 2 Ah |
| Line diameter | 2 mm |
| Product color | Multicolor |
| Plant protector | Yes |
| Rotational speed | 8300 RPM |
| Cutting diameter (max) | 33 mm |
Weight and Dimensions| Weight | 3600 g |
|---|
Keep work area clean, well-lit, and free from explosive atmospheres.
Follow guidelines for plugs, grounding, water exposure, cords, and RCDs.
Stay alert, use PPE, prevent unintentional starts, dress properly, and maintain balance.
Use the correct tool for the job and ensure it is in good working order.
Keep tools sharp, clean handles, and store safely away from children.
Use specified chargers and battery packs, and handle with care.
Have the tool serviced by qualified personnel using identical replacement parts.
Read instructions, wear eye protection, use in daylight, and check for damage.
Store out of reach of children, disconnect battery after use, and use approved parts.
Do not dismantle, short-circuit, expose to heat/shock, or allow contact with leaking liquid.
Charge before use, use specified chargers, and maintain terminals clean.
Store away from metal objects, keep out of reach of children, and remove when not in use.
Dispose properly, keep separate, and retain literature for reference.
Align and insert shaft into upper housing, then tighten locking knob.
Slide auxiliary handle onto support until click, ensure clamp is closed.
Remove screw, attach guard to housing, secure with screw, remove line cutter tape.
Battery pack is shipped uncharged and must be charged before first use.
The Li-Ion battery is protected against deep discharging.
Depress release button to remove; push in until click to install.
LEDs show charge level: three green = high, two = moderate, one = depleted.
Use lock-off switches and on/off lever to start; head continues to rotate briefly after shutdown.
Select speed for light, medium, or tough grass trimming.
Adjust handle for comfort and balance, then tighten clamp.
Wear PPE, hold tool correctly, ensure line is fed, use correct line diameter.
Rotate trimmer head to 180 degrees for edging, use edge guide for protection.
Line feeds automatically when switched on; noise is normal.
Press feed button and pull line; adjust length if too long.
Press and hold latches, then pull cap away from spool holder.
Remove old spool, clear debris, install new spool, release line, refit cap.
Insert line into spool holes, wind in direction of arrows, leave end in cleat.
Remove battery pack after use and store in a dry, protected place.
Remove battery, check for damage, clean with dry cloth, keep ventilation clean.
Switch off machine and remove battery before troubleshooting.
