2 in 1 Cordless Trimmer/Edger EN
12
ASSEMBLY & OPERATION
Action Figure
ASSEMBLY
Assembling the Safety Guard See Fig. A1 & A2
Mounting the Edger Wheel See Fig. B
Installing and Removing the
Battery Pack
See Fig. C
Charging the battery pack
More details can be found in
charger’s manual
Warning! The charger and
battery pack are specially
designed to work together
so do not attempt to use any other
devices. Never insert or allow me-
tallic objects into your charger or
battery pack connections because
of an electrical failure and hazard
will occur.
See Fig. D1, D2,
D3
OPERATION
Safety ON/OFF Switch See Fig. E
Trimming
- Adjusting the Shaft See Fig. F
- Adjusting the Trimmer Head See Fig. G1, G2
- Adjusting the Auxiliary handle See Fig. H
- Trimming See Fig. I1
- Using the Flower Guard See Fig. I2
Edging
- Changing the tool into the
Edging mode
See Fig. J1,
J2, J3
- Edging See Fig. K
Command feeding the line See Fig. L
Manually feeding the line
See Fig. M
Replacing the trimmer Spool
See Fig. N1, N2, N3
Manually winding the line
See Fig. O1, O2,
O3, O4
Spool holder
Note: Allows for an additional
spool to be stored on the tool.
See Fig. P
LINE FEEDING/WINDING
INSTRUCTION
1. Automatic line feed system
When initially switching on the trimmer, a small
length of line is fed out. Each time the tool is started
from rest it will advance about 0.25 inches of trimmer
line.
A ‘clattering’ noise will be heard when the lines hit
the Line Cutter. DO NOT BE ALARMED. This is quite
normal. After about 5 seconds the line will be cut to
the correct length and the noise will reduce as the
motor gains full speed.
If the noise of the line being cut can’t be heard, more
line will need to be fed out.
To feed more line, it is first necessary to allow the
trimmer to stop completely; it must come to a
complete rest, then restart, allowing the motor to
reach full speed.
Repeat above until you hear the line hitting against
the Line Cutter.
2.
TM
(See Fig. L)
Your trimmer is equipped with a Command Feed
System. For efficiently feeding the line, just press the
command feed button while the machine is running
until you hear the ‘clattering’ noise of the line cutting.
The motor will shut off when pressing the Command
Feed button and will restart when releasing the
button. During that process the line will automatically
feed additional line for cutting.
3. Manually feeding the line (See Fig. M)
Turn off the trimmer and remove the battery. If
required, line can be fed out manually. To operate,
press and release manual Line Feed Button, while
gently pulling out the line until it is long enough to
reach the Line Cutter. If the line extends past the Line
Cutter, too much line has been fed out. If too much
line is fed out, remove the Spool Cap and turn Spool
counter-clockwise until the line is at the desired length.
4. Manually winding the line
( See Fig. O1, O2, O3, O4)
Take approximately 10ft (3m) of line. Insert 5/8 inch
(15mm) of line into the Spool holes and wind line in
the direction of the arrows on the top of the Spool.
Leave approximately 4 inches (100mm) of line
unwound and place into the cleat. Ensure that the
line is neatly coiled on the Spool. Failure to do so will
impair the efficiency of the automatic line feed. Then
fit the Spool as shown in Fig. N1, N2, N3
