Worx WG305.2 - Page 11

Electric Chain Saw EN
11
1. REAR HANDLE
2. ON/OFF SWITCH/TRIGGER
3. LOCK-OUT BUTTON
4. OIL LEVEL WINDOW
5. OIL FILLER CAP
6. FRONT HANDLE
7. HAND GUARD
8. BUMPER SPIKE
9. GUIDE BAR
10. CHAIN
11. CHAIN TENSIONING KNOB
12. CHAIN COVER
13. EXTENSION CORD HOLDER
14. REAR HAND GUARD
15. DRIVE SPROCKET
16. CHAIN DIRECTION SYMBOL
17. OIL OUTLET
18. BAR PAD
19. FASTENING BAR HOLE
20. BAR LOCATING TABS
21. BAR AND CHAIN STORAGE/TRANSPORTATION COVER (SHEATH)*
22. BAR TENSIONING PLATE (See Fig. A )
23. PUMP BUTTON/BULB
* Not all the accessories illustrated or described are included in standard delivery.
