Guarded electric chain saw EN

1. POWER CORD

2. LOCK OUT BUTTON

3. REAR HANDLE

4. TRIGGER SWITCH

5. OIL LEVEL WINDOW

6. OIL FILLER

7. FRONT HANDLE

8. MOTOR

9. JAW TEETH

10. GUIDE BAR

11. SAW CHAIN

12. CHAIN ACCESS COVER

13. CHAIN ACCESS COVER NUT

14. AUXILIARY POSITION

15. CHAIN TENSIONER BOLT

16. SPROCKET

17. LOCK PIN

18. LOCK PIN RECEPTACLE (See Fig. B)

19. OIL BOTTLE

20. EXTENSION POLE (ONLY FOR WG308, See Fig. Z4)

21. CABLE HOOK

Not all the accessories illustrated or described are included in standard delivery.
