Chain Saw ENChain Saw EN
76
1. REAR HANDLE
2. ON/OFF SWITCH
3. LOCK-OFF BUTTON
4. OIL LEVEL WINDOW
5. OIL FILLER CAP
6. FRONT HANDLE
7. HAND GUARD
8. BUMPER SPIKE
9. GUIDE BAR
10. CHAIN
11. CHAIN TENSIONING KNOB
12. CHAIN COVER
13. EXTENSION CORD HOLDER
14. REAR HAND GUARD
15. DRIVE SPROCKET
16. CHAIN DIRECTION SYMBOL
17. OIL OUTLET
18. BAR CLAMP
19. FASTENING BAR BOLT
20. BAR LOCATING TABS
21. BAR AND CHAIN STORAGE/TRANSPORTATION COVER
22. BAR TENSIONING PLATE (SEE FIG. A)
23. EXTENSION POLE HANDLE
24. LOCKING COLLAR
25. CLAMPING LEVER
26. INNER POLE
27. HANDLE BRACKET
28. KNOB
29. RECEPTACLE CORD
* Not all the accessories illustrated or described are included in standard delivery.
TECHNICAL DATA
WG309 WG310
Voltage 120V~60Hz
Amps 8 A
Bar length 10“ 8”
Chain speed 8.5m/s
Oil tank capacity 120ml
Chain pitch 3/8”
Number of chain links 40 34
Chain gauge 0.050” 0.043”
Chain type A1-40 A0-34
Bar type P010-50SR P08-43SR
Weight(chain & bar included) 10lbs 9.5lbs
Protection class
/II
ACCESSORIES
Chain 1
Bar 1
Transportation Cover 1
Extend pole 1
Only use the appropriate accessories intended for this tool. Accessory information can be found
on the product packaging, at a WORX dealer or on our website at www.worx.com.
