Cordless Chain Saw EN
20
When replacing the chain turn the chain bar
180° to allow even wear, thus extending chain
bar life.
Check drive sprocket. If it is worn out or
damaged due to strain, have it exchanged by
an authorized service agent.
If the chain bar is worn out or damaged,
take the chain tensioning catch off the bar
by loosing the screw anti-clockwise. Then
fit the tensioning catch into the new bar by
tightening the screw clockwise. The catch
protrude (a) must be fitted into the bar hole.
(See Fig. W)
Sharpening Chain
WARNING: Remove the battery
pack from the saw before
servicing. Severe injury or death could
occur from electrical shock or body
contact with moving chain.
Cutting edges on chain are sharp. Use
protective gloves when handling chain.
Keep chain sharp. Your saw will cut faster and
more safely. A dull chain will cause undue
sprocket, guide bar, chain, and motor wear. If
you must force chain into wood and cutting
creates only sawdust with few large chips,
chain is dull.
Lubricate Sprocket
WARNING: Wear heavy duty gloves
when performing an maintenance or
service to this tool.
Always remove the battery pack from the saw
before performing any service or maintenance
on this tool.
NOTE: It is not necessary to remove the chain
or bar when lubricating the sprocket.
1. Clean the bar and sprocket.
2. Using a grease gun, insert the tip of the
gun into the lubrication hole and inject
grease until it appears at the outside edge
of the sprocket tip. (See Fig. X)
3. To rotate the sprocket release the chain
stop and pull the chain by hand until the
ungreased side of the sprocket is in line
with the grease hole. Repeat the lubrication
procedure.
CLEANING/STORAGE
Clean the moulded plastic housing of the
chain saw using a soft brush and clean
cloth. Do not use water, solvents or polishes.
Remove all debris, especially from the motor
cooling vents.
Remove and brush clean the cover plate,
chain and chain bar after 1 to 3 hours of use.
Clean the area under the cover plate, the drive
sprocket and chain bar assembly using a soft
brush. Clean oil outlet with a clean cloth.
If the chain saw is to be stored for a longer
period of time, clean chain and chain bar.
Store in a secure, dry place out of the reach of
children.
Do not place other objects on the chain saw.
To prevent leakage ensure machine is left in a
horizontal position (oil filler cap 4 uppermost).
When storing machine in original packaging
the oil tank must be completely emptied.
ENVIRONMENTAL
PROTECTION
Waste electrical products must not be
disposed of with household waste.
Please recycle where facilities exist.
Check with your local authorities or retailer for
recycling advice.
