Worx WR206E Installation Manual

11
EN
5. MACHINE SETTING
Advanced functions via the built-in interface
Despite its minimalistic design, you can set several advanced functions through the built-in control panel.
However, for the best user experience, we recommend you to use the free Landroid Vision App to do this, given its much richer
and intuitive interface.
5.1 Settings (See Fig. 34)
A. To access the main menu, rotate clockwise.
B. Rotate to select the menu items: “General settings” , “Working time” , “Security” , then press to enter.
C. Use the same procedure for the following actions.
5.2 Set date and time (See Fig. 35)
A. Return to “General settings”.
B. Rotate clockwise to select “Set date & time”, then press to enter.
C. Rotate clockwise to select the date, then press to confirm. The selected options (day, month or year) will start flashing.
D. Rotate to select the day, month or year and press quickly to confirm. Use the same method to complete the “Year / Month /
Time”.
5.3 Set work schedule (See Fig. 36)
NOTE: It is possible to set two work schedules per day: “Scheduler #1” and “Scheduler #2”.
A. Return to the main menu and rotate clockwise to select “Working time”, then press to enter.
B. Rotate clockwise to select “Customize work time”, then press to confirm.
C. Rotate clockwise to select the day of the week, then press to confirm.
D. Press to enter settings.
E. Rotate clockwise to activate “Scheduler #1 *”. Press to confirm.
F. Rotate clockwise. Select the start time “Hour/minute” and press to enter. The selected number will start flashing.
G. Rotate to select the time you want the Landroid Vision to start working on that day, and press to confirm. Follow the
same procedure to set the time to stop work.
H. Next, rotate clockwise to select “Border cut” and press to enter settings.
I. Rotate clockwise to choose whether or not to activate “Border cut” and press to confirm.
J. If you want to set a second working time (“Scheduler #2”), follow the same procedure.
K. Press the button and follow the same procedure to set the other days of the week.
* Be continuously updated according to the software version.
** Only shown for WR213E and WR216E
*** For after-sales service only
General settings
Working time
Security
Navigation
Page *
Language
Time format
Date format
Set date & time
Rain start delay
App link
Lawn explore
Blade height adjust**
Diagnose***
Auto Work Time
Customize work time
Change PIN code
Auto-Lock

Worx WR206E Specifications

General

Type	Robotic lawn mower
Bluetooth	Yes
Noise level	59 dB
Display type	LCD
Cutting width	180 mm
Product color	Black, Orange, Red, Silver
Cutting system	Rotary blades
Number of blades	3
Number of wheels	3 wheel(s)
Maximum lawn area	600 m²
Mulching function	-
Maximum cutting height	60 mm
Minimum cutting height	30 mm
Suitable for slope up to	30 %
International Protection (IP) code	IPX5
Battery type	Built-in battery
Power source	Battery
Battery capacity	2 Ah

Weight and Dimensions

Depth	626 mm
Width	460 mm
Height	265 mm
Weight	13500 g
