Page 14 of 39 WIM-TD-002_C
3.0 Installation
Caution
Follow safety guidelines utilizing lockout tagout
procedures before and during all installation and
maintenance procedures.
Warning
Ensure that proper rated lifting devices & procedures are
followed when installing, working or maintaining unit.
Failure to do so may result in equipment damage,
personal injury and even death.
Caution
Proper alignment is necessary to ensure that the friction
discs track properly. Improper alignment will result in
poor function and reduced service life.
Warning
Use only the proper quantity and grade of fasteners
shown in the drawings. Failure to do so may result
in fastener failure and/or a reduction in unit torque.
