Page 2 of 39 WIM-TD-002_C
Contents
Signal Words & Definitions
1.0 Introductions
1.1 Product Description
2.0 Exploded Views of Basic Units & Parts List for:
• “C” Style Clutch assembly
• “SP” Style Clutch assembly
3.0 Installation
3.1 Requirements for Proper Operation and Service Life
3.2 Outboard Support
3.3 Driving Ring
3.4 Installing the Unit
3.5 Clutch Adjustment
4.0 Operation
5.0 Disassembly
6.0 Assembly
7.0 Maintenance
7.1 Maintenance Schedule
8.0 General Storage Guidelines
9.0 Tables
• Speed and Size Availability
• SAE Flywheel & Housing Dimensions
• “C” & “SP” Style Lubrication Schedule
• Bolt Torque Values
10.0 Appendices
Appendix A - General
Sideload Information
OEM Clutch Pack Installation & Maintenance instructions
11.0 Trouble shooting guide
