Page 37 of 39 WIM-TD-002_C
OEM Clutch Pack
OEM Clutch Pack Installation and Maintenance Instructions
Refer to the specific WPT clutch pack drawing as needed.
Installing the Clutch Pack on the Shaft:
1. See section 6.1.4 in this manual.
2. Torque specification for hub nut see Appendix A.
Aligning the Friction Discs and Assembling with the Engine:
1. See section 3.3 Installation in this manual.
2. Disengage the PTO after mounting to the Engine is complete.
Maintenance:
1. Maintenance schedule:
• See section 7.1 in this manual.
2. Lubrication:
• See section 7.1 in this manual.
3. Clutch Adjustment
• See section 3.5 in this manual.
Clutch Operation:
• See section 4.0 in this manual.
