WPT POWER PILOTLESS - C & SP Style Lubrication Schedule

Page 32 of 39 WIM-TD-002_C
Reference J617 table 1A
SAE
Housing
Distance
00
0.019 inches (0.483mm)
0
0.016 inches (0.406mm)
1
0.012 inches (0.305mm)
2
0.011 inches (0.279mm)
3
0.010 inches (0.254mm)
4
0.009 inches (0.229mm)
5
0.008 inches (0.203mm)
6
0.007 inches (0.178mm)
Table 5
“C” & “SP” Style Lubrication schedule
Component
Interval
Lubrication
Main Bearings
See Chart 1, Section 7.1.2
NLGI #2 lithium based grease
Operating Shaft
Approx. 1 to 3 shots every 3
months or 100 hours of Operation
NLGI #2 lithium based grease
Sliding Sleeve Sealed
Ball Bearings
Inspect every 2 years
or 2000 hours
Seal for Life
(Discard as Required)
TABLE 6
TABLES
