WPT POWER PILOTLESS - Tables

Page 30 of 39 WIM-TD-002_C
Model/ Size
Available SAE
Housing Sizes
Maximum Input
Torque lbfft (Nm)
Maximum
Speed
rpm
Approx. Net
Weight
lb (kg)
C106
6,5,4
171 (232)
3500
60 (27)
C107
6,5,4
191 (259)
3200
72 (32)
C108
5,4,3
248 (336)
3100
83 (37)
C110
4,3,2
354 (481)
2800
117 (53)
SP111
3,2,1
487 (660)
2500
143 (64)
SP211
3,2,1
974 (1321)
2500
157 (71)
SP311
3,2
1746 (2367)
2300
223 (101)
SP114
1,0
862 (1169)
2300
263 (119)
SP214
1,0
1724 (2337)
2300
332 (150)
SP314
1,0
2586 (3506)
2300
413 (187)
Table 3
Contact WPT for applications requiring higher speeds.
FLYWHEEL (SAE J620) AND HOUSING DIMENSIONS (SAE J617)
FLYWHEEL DIMENSIONS
Clutch size
A
B
C
N1
H1
6”
7.25 (184.2)
8.500 (215.90)
7.875 (200.02)
6
5/16 – 18 NC
7”
8.12 (206.2)
8.750 (222.25)
9.500 (241.30)
8
5/16 – 18 NC
8”
8.88 (225.6)
9.625 (244.48)
10.375 (263.52)
6
3/8 – 16 NC
10”
10.88 (276.4)
11.625 (295.28)
12.375 (314.32)
8
3/8 – 16 NC
11”
12.38 (314.5)
13.125 (333.38)
13.875 (352.42)
8
3/8 – 16 NC
14”
16.12 (409.4)
17.250 (438.15)
18.375 (466.72)
8
1/2 - 13 NC
FLYWHEEL HOUSING DIMENSIONS
Housing size
D
E
N2
H2
6
10.500 (266.70)
11.250 (285.75)
8
3/8 – 16 NC
5
12.375 (314.33)
13.125 (333.38)
8
3/8 – 16 NC
4
14.250 (361.95)
15.000 (381.00)
12
3/8 – 16 NC
3
16.125 (409.58)
16.875 (428.63)
12
3/8 – 16 NC
2
17.625 (447.68)
18.375 (466.73)
12
3/8 – 16 NC
1
20.125 (511.18)
20.875 (530.22)
12
7/16 - 14 NC
1/2
23.000 (584.20)
24.375 (619.12)
12
1/2 - 13 NC
0
25.500 (647.70)
26.750 (679.45)
16
1/2 - 13 NC
00
31.000 (787.40)
33.500 (850.90)
16
1/2 – 13 NC
Table 4
See page 31 for flywheel and housing drawing.
TABLES
