Page.9.
20
The power indicator: it lights green while the tester is powered on by the adapter
21
The data accepted indicator: it lights red while the data is being received
22
The RS485/RS232 data transmission indicator: it lights red while the data is being
transmitted
23
The charge indicator: it lights red while the battery is being charged. As the
charging is complete, the indicator turns off automatically
Top interface
Left interface Right interface
