RS485 Interface: RS485communication for the PTZ
25
RS232 Interface: RS232 communication for the PTZ"HD IN" , AHD /TVI/CVI Coaxial
interface (Optional )
26
DC12V2A power output , for provisional DC power supply
27
TDR cable test interface
28
LED lamp
29
SDI input (BNC interface) (Optional)
30
HDMI input
31
Video image signal output（BNC interface）/cable tracer interface (Optional)
32
Video image signal input（BNC interface）/ AHD,CVI and TVI input (BNC interface)
(Optional)
33
Optical power meter interface (Optional)
34
Visible red laser source emits Interface (Optional)
35
UTP cable port: UTP cable tester port/ Cable tracer port
36
Micro SD card moveable, comes with 8GB, supports up to 32GB
37
Audio input
38
HDMI output interface
39
Audio and earphone output
40
5V2A USB power output , as power bank
41
DC12V2A charging interface
42
PSE power sourcing equipment. Tests PoE voltage
43
PoE power supply output or LAN test port (Use to test PoE or non-PoE IP camera)
