DigiReader Series
16 P/N 6600025, REV. D
S-Net cable should only be installed in a daisy-chained fashion. WSE strongly recommends
replacing all crimp lug/soldered splices by daisy-chained connections in and out of each device.
(Note that up to two AD4305 NexStar RS485 Multiplexers may be used to simplify wiring and extend
a network.)
Where a pigtail cable is provided with the reader, a splice is required and the installer should, if
possible, keep the splice within 3 feet of the reader, to allow splice inspection at the reader location.
The type of cable used for the S-Net should be separate twisted-pair (data and power). See Table
5, above, for WSE recommended S-Net cables.
WIEGAND CONNECTIONS
Refer to Table 11 for the proper wire size for a particular cable length to use in a DigiReader Wiegand
application. Figure 6, below, illustrates a typical Wiegand connection.
Table 11: Recommended Wiegand Cable Gauge
DLEIHSHTIWELBACDNAGEIWROTCUDNOC-6
eziSeriWmuminiMhtgneLmumixaM
GWA22teeF002
GWA02teeF003
GWA81teeF005
