ENGINE
WG972-E4, WSM
1-M14
[2] FUEL FILTER (GASOLINE LINE) [WG972-GL, WG972-G]
The fuel filter is installed in the fuel line between the
fuel tank and the feed pump.
As the fuel flows from the inlet "A" through the filter
element (1), the dirt and impurities in the fuel are filtered,
allowing only clean fuel to penetrate the inside of the
filter element. The cleaned fuel flows out from the outlet
"B".
9Y1211108ENM0028US0
Type of filter element Accordion-pleated paper type
Material of filter element Cotton fiber
Filter mesh 15 µm (0.00059 in.)
(1) Filter Element A: Inlet
B: Outlet
