Airframe Assembly
Preparation
Remove Spraying Hub Housing
Remove Spraying Hub Housing by unscrewing its 6 screws (2 on the top and 2 on both left side and right
side )
Remove Central Cabin Cover and Arm Bracket
Pull o󽗈 the Liquid Tank Sensor Cable on the Spraying Hub.
Liquid Tank Sensor
Cable
