AC Panel
975-0128-01-01 2–3
6 Status Display: Shows Voltage, Current or AC Power.
VOLTAGE: Indicates battery power at the input terminal of the
inverter in volts (V).
CURRENT: Indicates current drawn from the battery by the inverter
in amps (A).
AC POWER: Indicates the output power from the inverter as a
percentage of total available watts being utilized.
7 Two 15 A Breakers
8 3-Prong AC Outlets: Each outlet is protected by a 15-amp breaker.
9 AC Knockout: For hardwiring the inverter.
10 Remote On/Off Connector Port: For connecting the Remote On/
Off Switch.
11 Mounting Flanges (front and rear) allow you to mount the inverter
permanently.
12 Ventilation Openings must not be obstructed for the proper
operation of the inverter. When the inverter is mounted, the
ventilation opening on the DC panel must not point up or down.
Feature Description
