A–1
A Specifications
Appendix A contains electrical performance and physical specifications
for the inverter.
Electrical Performance
Physical Specifications
Specifications are subject to change without notice.
Output power at 25ºC (77ºF) ambient
temperature and 12 V dc input:
• Maximum continuous output power
• 5 minute rating
2500 W
3000 W
Output voltage 115 V AC RMS ± 5 %
Output waveform Modified sine wave
Output frequency 60 Hz ± 4 Hz
Input voltage 10.5–15.0 VDC
Low battery alarm 11.0 V
Low battery cutout 10.5 V
Optimum efficiency 90%
No load current draw <0.6 A dc
Length
18 1/2" (47 cm)
Width 8" (20 cm)
Height
6 1/4" (16 cm)
Weight 20 lb. (9 kg)
XPower3000.book Page 1 Wednesday, December 10, 2003 6:52 AM
