Specifications
A–2 975-0082-01-01
Electrical Specifications
*Limited to Class 2 levels (100 VA) as in Chapter 2, page 2–6.
Mechanical Specifications
Nominal input network voltage 15 VDC
Minimum operating network voltage 14.25 VDC
Maximum operating network voltage 15.75 VDC
Maximum operating current 200 mA @ nominal
input network voltage
Relay contact voltage rating 12 VDC, 30 VDC max.
Maximum relay current 5 A DC*
Nominal 12 V/24 V thermostat input voltage 12 VDC/24 VDC = On
Minimum 12 V/24 V thermostat input voltage 9.5 VDC
Maximum 12 V/24 V thermostat input voltage 30 VDC
Typical 12 V/24 V thermostat input current 14.6 mA @ 12 V
Nominal 12 V/24 V generator running B+ voltage 12 VDC/24 VDC= On
Minimum 12 V/24 V generator running B+ voltage 9.5 VDC
Maximum 12 V/24 V generator running B+ voltage 30 VDC
Typical 12 V/24 V generator running B+ current 14.6 mA @ 12 V
Communication physical layer 2, CAN
Communication protocol Xanbus
Maximum cable length 130 ft. (40 m)
Dimensions
5 × 3 × 1 "
(146 × 95.5 × 37 mm)
Weight 0.5 lb. (225 g)
Mounting 4 #6 screws
Connectors 2 × Xanbus: RJ45—8 pins
20-contact pluggable connector
(Tyco Mate ’n’ Lok 2 connector)
3
4
---
3
4
---
1
2
---
