3
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . 4
Things You Should Know . . . . . . . . . . . . . 5
Circuit Breaker Protection
Thermostat Controlled Cooling
Inverter Idle Circuit
Low and High Battery Shutdown
Power Sharing
Temperature Sensitive Charging
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Optional Remote Control Panels . . . . . . . . .10
Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Battery Types
Battery Interconnection
Battery Bank Ratings and Sizing
Battery Charging. . . . . . . . . . . . . . . . . . . . 15
Freedom Battery Chargers
Battery Charger Voltage Settings . . . . . . .20
Installation Precautions . . . . . . . . . . . . . . 21
Installation . . . . . . . . . . . . . . . . . . . . . . . . . 22
Key Installation Points
Grounding
Neutral Bonding
AC Wiring
AC Input
AC Output
Ground Fault Circuit Interrupters
Remote Control Wiring
TSC Temperature Sensor
DC Wiring
Battery Cable Fusing
Power ON Checks
TABLE OF CONTENTS
Troubleshooting . . . . . . . . . . . . . . . . . . . . .31
LED Fault Status
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 35
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Installation Examples. . . . . . . . . . . . . . . . . . . 39
Not recommended for use in a marine environment
To Next Page
