Prosine 2.5/3.0 Installation & Operation Guide 23
Section 2: Controls and Indicators
Battery Temperature Sensor
The temperature sensor continuously measures the temperature of the battery and adjusts charger
output for a more accurate, temperature-compensated charge.
Figure 4. Battery Temperature Sensor
Feature Description
!
Mounting plate. Connects to the negative battery terminal.
"
Sensor. Reverse side has peel-off backing and self-adhesive strip so
you can attach the sensor to the side of the battery case.
#
Sensor cable (25ft; 8m).
NOTE: The battery temperature sensor is electrically isolated from the
mounting plate.
!
"
#
