Prosine 2.5/3.0 Installation & Operation Guide 79
Appendix A: Specifications
INVERTER
Prosine 2.5 12-volt;
(24-volt in parenthesis)
Prosine 3.0 12-volt;
(24-volt in parenthesis)
Continuous output power /
current
2500W / 21A RMS 3000W / 25A RMS
Surge rating (5 seconds) 4000W 4000W
Peak output current 50A 50A
Peak inverter efficiency 88% 88%
No load current draw, in load
sense mode
<3W <3W
Idle circuit adj. load sensing OFF, 10W, 25W, 50W [dip
switches]
OFF, 10W, 25W, 50W [dip
switches]
No load current draw, inverter
idle
60W 60W
Output frequency 60Hz ± 0.05% (crystal con-
trolled)
60Hz ± 0.05% (crystal con-
trolled)
Output waveform Sine wave <5%THD Sine wave <5%THD
Input voltage range 10-16Vdc (20-32Vdc) 10-16Vdc (20-32Vdc)
Output voltage (at no load) 120Vac RMS ± 3% 120Vac RMS ± 3%
Output voltage (over full load
& battery voltage range)
120Vac RMS -10% / +4% 120Vac RMS -10% / +4%
Low Battery Cut-out 10Vdc, 10.5Vdc warning
(20Vdc, 21Vdc warning)
10Vdc, 10.5Vdc warning
(20Vdc, 21Vdc warning)
High Battery Cut out 16Vdc (32Vdc) 16Vdc (32Vdc)
Protection Automatic overload, short cir-
cuit, overtemperature
Reverse polarity (fuse)
Automatic overload, short cir-
cuit, overtemperature
Reverse polarity (fuse)
CHARGER
Battery capacity selections 50, 75, 100, 150, 200, 300,
400, 500, 600, 700, 800, 1000,
1200, 1400, 1700, >2000
50, 75, 100, 150, 200, 300,
400, 500, 600, 700, 800, 1000,
1200, 1400, 1700, >2000
Charge Rate 12V (24V) 100A (50A) 120A (60A)
Charger Power Factor Rating .99 .99
Charger Efficiency > 80% > 80%
Charge banks 1 high current 1 high current
Charge control 3-stage with manual equalize 3-stage with manual equalize
Temperature compensation 3 settings or optional sensor 3 settings or optional sensor
Electrolyte compensation flooded/gel flooded/gel
Input voltage range 90-135 Vac 90-135 Vac
AC service setting [max. cur-
rent draw]
10 [8], 15 [12], 20 [16] , 30 [24]
amps
10 [8], 15 [12], 20 [16] , 30 [24]
amps
Transfer Relay rating 30A 30A
