Xantrex truecharge 2 series User Manual

975-0526-01-02 43
Accessing Charger Information
Table 9 Interpreting Fault and Warning Indicators
Fault or Warning
Condition
Temp Fan AC Battery Fuse Charger Remote Fault
Solution
AC input out of range
fault (<85 V or >265 V)
• Check AC connections. Change to a more stable AC
power source and check that the voltage and voltage
frequency are within acceptable operating range. See
“Specifications” on page 54.
High Battery Temp fault
(>70°C)
• Check the batteries. Do not charge a battery that is
rated other than 12 V nominal for all 12-volt chargers
or 24 V nominal for all 24-volt chargers. Check that
the battery type and temperature settings match the
actual battery and its conditions.
• Disconnect or turn off other charging sources such as
an alternator or the charger on a generator with an
electric start.
• Allow the battery (or batteries) to cool to normal
operating temperature. See “Specifications” on page
54.
Flashing LED Solid LED
F
u
s
e
C
h
g
r
R
e
m
TC2 204060 Series BattChg Owners Guide.book Page 43 Friday, July 8, 2011 11:44 AM

Xantrex truecharge 2 series Specifications

General

Input Voltage	90-265 VAC
Input Frequency	47-63 Hz
Number of Banks	3
Dimensions	Varies by model
Weight	Varies by model
Output Voltage	12 VDC or 24 VDC
Output Current	20A, 40A, or 60A
Battery Types	Flooded, Gel, AGM
Charging Stages	3-stage (Bulk, Absorption, Float)
Protection Features	Overvoltage, Overcurrent, Short Circuit, Reverse Polarity, Over Temperature
Operating Temperature	-20°C to +50°C
