975-0526-01-02 49
Replacing the DC Output Fuse
Fuse Replacement Ratings
RISK OF EQUIPMENT DAMAGE
For continued protection, replace only with Littelfuse
®
type 257 (or
equivalent) with ratings as shown below.
Failure to follow these instructions can damage the unit and/or
damage other equipment.
Model Amperage Voltage
TC2012 30 A (green) 32 Vdc
TC4012 2×30 A (green) 32 Vdc
TC6012 3×30 A (green) 32 Vdc
TC1024 30 A (green) 32 Vdc
TC2024 15 A (blue) 32 Vdc
TC3024 40 A (amber) 32 Vdc
TC2 204060 Series BattChg Owners Guide.book Page 49 Friday, July 8, 2011 11:44 AM
