Xerox 8254E / 8264E Color Wide Format Printer
User Guide
5-8
Printing-related Troubleshooting
1. Printing is partially stained or incomplete.
Note:
Proper print quality may not be obtained with media other than recommended ones.
2. The printing position is incorrect (areas of the media cannot be printed)
3. Printing is blurred
No. Possible cause Remedy Reference
1 Has the media absorbed
moisture?
Replace it with new media. Replacing Roll Media
2 Are you using folded or
wrinkled media?
3 Does the media bend? Use recommended media.
When using media other than the
dedicated one, set the Vacuum Fan
menu.
Media Type
Vacuum Fan Menu
No. Possible cause Remedy Reference
1 Is the loading position of the
media correct?
Set the media correctly. Setting Roll Media
2 Did you set up the origin and
print position?
Cancel or reset the settings of the
origin and print position.
Menu Overview
No. Possible cause Remedy Reference
1 Are you using recommended
media?
Use recommended media. Media Type
2 Are you using thick or thin
media?
Use recommended media. Media Type
3 Is the media printed on the
printing surface?
Confirm the printing surface of
the media and set it correctly.
Media Handling
4 Did you perform Alignment? Perform Alignment. Adjust Print
5 Did you perform Media feed
compensation?
Perform Media feed
compensation.
Media Feed Compensation
6 Is each heater set to the
appropriate temperature?
Set each heater to the
appropriate temperature.
Pre-Heater Menu through
After Heater menu
7 Is the head height set to "High?" Return the head height to
"Normal (Low)".
Head Height Adjustment
