Xerox 8264E - Page 206

Xerox 8254E / 8264E Color Wide Format Printer
User Guide
5-22
6. 8264E only
a. Turn the flanges of the roll media holders and wind roll media backwards, onto its spool.
7. 8254E only
a. Turn the flanges of the roll media holders and wind roll media backwards, onto into spool.
8. If paper dust or pieces of paper remain inside the printer, remove them. Try to do so without
blowing paper dust inside the printer.
No. Name
1 Flanges
2 Roll media
No. Name
1 Roll media
2 Scroller
