Xerox 8254E / 8264E Color Wide Format Printer
User Guide
6-11
4. Remove the scroller from the printer, and place it on a horizontal surface.
5. Turn the movable flange back and forth while pulling it away from the roll media until it is
disengaged.
No. Name
1 Scroller
No. Name
1 Movable flange
2 Scroller
