Product Overview
Xerox 8254E / 8264E Color Wide Format Printer
User Guide
2-3
4 Stand Used to support the printer.
5 Media guide Used for feeding media smoothly when the media is set or printed.
The After Heater is installed under the guide.
6 Platen Installed inside of the front cover.
The Platen Heater is installed under the platen.
7 Pressurizing rollers Installed inside of the front cover.
Press and hold the media when printing.
8 Media cut groove Installed inside of the front cover.
Used to cut media straight.
9 Maintenance covers
(Right and Left)
Used to prevent the user from touching the inner mechanical section.
Opened and closed in the following cases.
• When cleaning the cleaning wiper
• When cleaning around the print head
It is normally closed.
10 Adjusters Used to level the printer on uneven floors.
11 Media holder plates
(Right and Left)
Installed inside of the front cover.
Used to engage both sides of the media, guiding the media and helping to
prevent buckling or warping.
No. Name Function
