Preparing For A Job
Xerox 8254E / 8264E Color Wide Format Printer
User Guide
3-29
5. Holding the front edge of the roll media, roll it backward, using the scroller flanges, to remove any
bend and/or slant in the media.
6. Lower the media loading lever.
No. Name
1 Roll media
2 Scroller flanges
