CClleeaanniinngg tthhee DDooccuummeenntt FFeeeedd RRoolllleerrss
Dirt on the document feed rollers can cause paper jams or deteriorate print quality. For best
performance, clean the document feed rollers once a month.
1. Lift the lever and open the top cover of the document feeder.
2. While turning the rollers, wipe the rollers with a clean, lint-free cloth moistened with water.
Note: There is a lint-free cloth stored in a compartment on the document feeder.
Caution: Do not use alcohol or chemical cleaners on the document feed rollers.
3. Close the document feeder top cover. If available, close the document feeder left cover.
218
Xerox
®
AltaLink
®
B81XX Series Multifunction Printer
User Guide
Maintenance
