Clearing Jams at Area 2g in the Tri-Fold Module
1. Open the front door of the tri-fold module.
2. Open the folder tray, move lever 2g to the right, then carefully remove the paper.
Note: If the paper is torn, remove all torn pieces of paper from the folder.
3. Return lever 2g to the original position, then close the folder tray.
4. Close the front door of the tri-fold module.
310
Xerox
®
AltaLink
®
B81XX Series Multifunction Printer
User Guide
Troubleshooting
