Clearing Jams at Area 2f in the Tri-Fold Module
1. Open the front door of the tri-fold module.
2. Open the folder tray, move lever 2f to the right, then carefully remove the paper.
Note: If the paper is torn, remove all torn pieces of paper from the folder.
3. Return lever 2f to its original position, then close the folder tray.
4. Close the front door of the tri-fold module.
