Xerox DocuMate 152i User Manual

Maintenance Xerox
®
DocuMate
®
152i
User Guide 21
8. Gently slide the roller to the left to fit its left end into its mount. Make sure the left end of the
roller is firmly seated into its mount.
If the gears on the end of the roller do not engage easily, slightly rotate the roller while gently
pressing it into the housing until you feel them engage.
9. When you are certain that the gears are engaged, rotate the lock tab into the scanner. Press
down on the lock flange to lock the roller into the scanner.
The lock will “click” into place when it is secure. However, if it does not rotate easily into the
housing, make sure the flange is properly seated in its latch.
10. Insert the scanner’s input tray back into the slots in the scanner body.
11. Push the tray back until it is fully seated into position.
