5-9
EXPLODED VIEWS AND PARTS LIST
Service Manual
NO DESCRIPTION SEC CODE Q’TY SA REMARK
0 ELA HOU-FUSER 110V TBD 1 O 110V
ELA HOU-FUSER 220V TBD 1 O 220V
1 COVER-FUSER JC63-00105A 1 X
2 HOLDER-PLATE CLAW JC61-00584A 4 X
3 SPRING ETC-CLAW JC61-00064A 4 X
4 PMO-ROLLER EXIT JC72-60059A 2 X
5 SPRING-EXIT F_UP JC61-70976A 2 X
6 THERMOSTAT-150 JC47-00005A O
7 PMO-GEAR_EXIT_DRV16 JC72-00143A 1 X
8 GEAR-IDLE 23 JC66-00396A 1 X
9 RING-CS 6044-000001 1 X
10 GEAR-RDCN 2515 JC66-00397A 1 X
11 IPR-ELECTRODE_LAMP JC70-00275A 1 X
12 ELECTRODE-WIRE_L JC70-00450A 1 X
13 THERMISTER-NTC HF 1404-001298 1 O
14 ELECTRODE-WIRE_R JC70-00449A 1 X
15 CBF HARNESS-FUSER(110V) JC39-00239A 1 O 110V
CBF HARNESS-FUSER(220V) JC39-00238A 1 O 220V
16 GEAR-FUSER,Z37 JC66-00564A 1 O
17 BUSH-HR_L JC61-00589A 1 X
18 NPR-ROLLER_HEAT JC66-00601A 1 O
19 BUSH-HR_R JC61-00590A 1 X
20 LAMP-HALOGEN(110V) TBD 1 O 110V
LAMP-HALOGEN(220V) TBD 1 O 220V
21 ROLLER-EXIT F_UP JC66-00380A 1 X
22 ROLLER-PRESSURE JC66-00600A 1 O
23 BEARING-PRESSURE JC66-10901A 2 X
24 SPRING-PR(1400) 6107-001168 2 X
25 PMO-BUSHING TX JC72-00382A 3 X
26 HOLDER-ACTUATOR JC61-00581A 1 X
27 PMO-ACTUATOR_EXIT JC72-00987A 1 X
28 IPR-FRAME_FUSER JC70-00317A 1 X
29 GUIDE-INPUT JC61-00595A 1 X
31 RMO-RUBBER_EXIT JC73-00017A 2 X
33 LABEL(P)-CAUTION, HOT_FUSER JC68-30928D 1 X
30 SPRING ETC-ACT_EXIT 6107-001165 1 X
32 NUT-HEXAGON 6021-000222 5 X
?? NEW-CLAW ASSY TBD 1 X
?? PLATE-CLAW JC61-00605A 4 X
< Fuser Unit Parts List >
SA. : Service Available
O: Service available X: Service not available
