2-2
Specifications
Service Manual
2.3 Electrical Specification
2.2 Controller Specification
ITEM
DESCRIPTION
Phaser 3120 Phaser 3130
Processor(CPU) Samsung Jupiter4 90MHz Samsung SPGPm 166MHz
OS Compatibility
(1)
Win 98x/NT4.0/ME/2000/XP,
Various Linux OS,Mac(Mac OS 8.6 ↑)
Memory FLASH ROM(PROGRAM) : 0.5MB flash
RAM : 8 MB RAM : 32 MB
EEPROM(NVRAM) : 512byte
Emulation SPL(Samsung Printer Language) PCL6, IBMProPrinter, EPSON
Interface USB 1.1 USB
- USB 2.0
- 12 Mbps 1 port
Parallel : IEEE 1284
- Modes supported :
Compatible,Nibble,Byte,ECP
External Network Adaptor(Optional)
Interface switching Automatic
Interface time-out 5min(Max.)
Font Windows Font 45 Scalable, 1 Bitmap
ITEM DESCRIPTION
Input Voltage Nominal input voltage 200-240 VAC / 100~127VAC
Input voltage range 189-264 VAC/ 90~132VAC
Nominal frequency 50/60 Hz
Frequency tolerance +3Hz
Power Consumption Printing : 280W Avg or less Power Save : 10W Avg or less
2.4 Environmental Range
ITEM OPERATING STORAGE
Temperature 10~32
o
C(50-90 oF) -20~40
o
C (-4~104 oF)
Humidity 20~80%RH 10~80%RH
(1) The SPL series model is USB exclusive use, so it supports the environment beyond the WIN 98.
