5-11
EXPLODED VIEWS AND PARTS LIST
Service Manual
NO DESCRIPTION SEC CODE Q’TY SA REMARK
0 CASSETTE JC97-01750A 1 O
1 FRAME-CASSETTE JC61-00578A 1 X
2 PMO-EXTENSION LARGE JC72-00970A 1 X
3 PMO-EXTENSION SMALL JC72-00971A 1 X
4 PLATE-KNOCK_UP JC61-00603A 1 X
5 SPRING-KNOCK_UP 6107-001166 2 X
6 HOLDER-PAD JC61-00580A 1 X
7 SPRING-FRICTION PAD JC61-70911A 1 X
8 ROLLER-IDLE FEED JC66-00529A 2 X
9 SPRING-FEED 6107-001047 2 X
10 PMO-PLATE_LOCKER JC72-00972A 1 X
11 SPRING-LOCKER JG61-70531A 1 X
12 ADJUST-CASSETTE_L JC70-00300A 1 X
13 ADJUST-CASSETTE_R JC70-00301A 1 X
14 GEAR-PINION JG66-40003A 1 X
15 INDICATOR-LEVER INDICATOR JC64-00040A 1 X
16 RPR-FRICTION PAD JC73-00140A 1 X
17 IPR-PLATE PAD JC70-00314A 1 X
18 RPR-PAD CASSETTE JC73-00141A 3 X
< Cassette Unit Parts List >
SA. : Service Available
O: Service available X: Service not available
