Xerox Phaser 3250 User Guide

Using Your Printer in Linux
30
Classes Tab
The Classes tab shows a list of available printer classes.
• Refresh : Renews the classes list.
• Add Class... : Allows you to add a new printer class.
• Remove Class : Removes the selected printer class.
Ports Configuration
In this window, you can view the list of available ports, check the status
of each port and release a port that is stalled in busy state when its owner
is terminated for any reason.
• Refresh : Renews the available ports list.
• Release port : Releases the selected port.
Shows the status of the
class and the number of
printers in the class.
Shows all of the
printer classes.
Switches to
ports
configuration.
Shows the port type,
device connected to the
port and status
Shows all of the
available ports.
Configuring Printer Properties
Using the properties window provided by the Printers configuration, you
can change the various properties for your machine as a printer.
1 Open the MFP Configurator.
If necessary, switch to Printers configuration.
2 Select your machine on the available printers list and click
Properties.
3 The Printer Properties window opens.
The following five tabs display at the top of the window:
• General: allows you to change the printer name, location and
description. The name entered in this tab displays on the
printer list in Printers configuration.
• Connection: allows you to view or select another port. If you
change the printer port from USB to parallel or vice versa
while in use, you must re-configure the printer port in this tab.
• Driver: allows you to view or select another printer driver. By
clicking Options, you can set the default device options.
• Jobs: shows the list of print jobs. Click Cancel job to cancel
the selected job and select the Show completed jobs check
box to see previous jobs on the job list.
• Classes: shows the class that your printer is in. Click Add to
Class to add your printer to a specific class or click Remove
from Class to remove the printer from the selected class.
4 Click OK to apply the changes and close the Printer Properties
Window.

Xerox Phaser 3250 Specifications

General

Color	No
Print technology	Laser
Maximum resolution	600 x 600 DPI
Warm-up time (from sleep mode)	15 s
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Maximum internal memory	160 MB
Sound power level (standby)	29 dB
Sound pressure level (printing)	54 dB
Total input capacity	251 sheets
Maximum input capacity	501 sheets
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Transparencies
Functions	Print
I/O ports	USB 2.0
Device manager	Printer Setting Utility for Windows
Package length	561.33 mm
Depth (imperial)	14.5 \
Width (imperial)	14.3 \
Height (imperial)	9.4 \
Weight (imperial)	26.19 lbs
Power requirements	240 V, 50/60 Hz
Storage drive type	N/A
Hardware scan resolution	1200 x 1200 DPI
Storage temperature (T-T)	32 - 104 °F
Power consumption (active)	400 W
Compatible operating systems	Fedora Core 1, Red Hat 9, SUSE 9 Windows 2000/Vista
Non-operating relative humidity (non-condensing)	20 - 80 %
Country of origin	China
Maximum duty cycle	30000 pages per month
Recommended duty cycle	4000 pages per month
Sustainability certificates	ENERGY STAR
Power consumption (standby)	70 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 80 %
Certification	CE, UL 60950-1/CSA 60950-1-03, EMC 2004/108/EC, 2006/95/EC
Package width	472.43 mm
Package height	342.89 mm
Package weight	11884.3 g

Weight and Dimensions

Depth	369 mm
Width	364 mm
Height	239.2 mm
Dimensions (WxDxH)	364 x 369 x 239.2 mm
