Xerox Phaser 6128MFP Quick User Guide

2120
www.xerox.com/office/6128MFPsupport
Scanning
Scanning
Ethernet
ABC
GHI
PQRS
-_~
TUV WXYZ
JKL MNO
@:./ DEF
1 2 3
4
5 6
7
8
0
#
9
Start
Enter Recipient
Email to... xybusiness@xyz
From Setting....
File Format... MultiPage TIFF
E-mail
Enter Recipient
Email to...
From Setting...
File Format... MultiPageTIFF
Recipient
Keypad...
Address Book...
Email Group...
Enter Email, [OK]: Save
xybusiness@xy_
3.1
3.2
OK
OK
OK
Phaser
®
6128MFP
Software and Documentation
EN
FR
IT
DE
ES
PT
Scanning to Email
Numérisation vers un courrier électronique
Scansione su e-mail
Scanausgabe: E-Mail
Exploración a correo electrónico
Digitalização para e-mail
Consultez la section Numérisation du Guide
d'utilisation pour de plus amples informations.
Per ulteriori informazioni, vedere la sezione
Scansione nella Guida dell'utente.
Weitere Informationen sind dem Kapitel Scannen
des Benutzerhandbuchs zu entnehmen.
Consulte Exploración en la Guía del usuario para
obtener más información.
Consulte Digitalização no Guia do Usuário para
obter informações adicionais.
EN
FR
IT
DE
ES
PT
See Scanning in
the User Guide for more information.
1
3
4
5
2
Appuyez sur le bouton Courriel.
Premere il pulsante E-mail.
Taste E-Mail drücken.
Pulse el botón Correo electrónico.
Pressione o botão E-mail.
EN
FR
IT
DE
ES
PT
Press the E-mail button.
Faites défiler pour sélectionner d'autres paramètres.
Scorrere per selezionare altre impostazioni.
Mit den Pfeiltasten weitere Einstellungen vornehmen.
Desplácese para seleccionar otras opciones.
Role para selecionar outras configurações.
EN
FR
IT
DE
ES
PT
Scroll to select other settings.
Appuyez sur le bouton Démarrer.
Premere il pulsante Avvio.
Taste Start drücken.
Pulse el botón Iniciar.
Pressione o botão Iniciar.
EN
FR
IT
DE
ES
PT
Press the Start button.
Faites défiler la liste et sélectionnez Courriel vers...,
puis appuyez sur le bouton OK.
Scorrere per selezionare Invia e-mail a..., quindi
premere il pulsante OK.
Mit den Pfeiltasten E-Mail senden an auswählen und
die Taste OK drücken.
Desplácese para seleccionar Enviar correo
electrónico a..., y luego pulse el botón Aceptar.
Role para selecionar E-mail para..., e pressione o
botão OK.
EN
FR
IT
DE
ES
PT
Scroll to select Email to..., and then
press the OK button.
Faites défiler la liste et sélectionnez le type d'adresse,
puis appuyez sur le bouton OK.
Scorrere per selezionare un tipo di indirizzo, quindi
premere il pulsante OK.
Mit den Pfeiltasten den Adresstyp auswählen und die
Taste OK drücken.
Desplácese para seleccionar un tipo de dirección y
luego pulse el botón Aceptar.
Role para selecionar um tipo de endereço e pressione
o botão OK.
EN
FR
IT
DE
ES
PT
Scroll to select an address type, and
then press the OK button.
Entrez une adresse électronique si nécessaire, puis
appuyez sur le bouton OK.
Se richiesto, immettere un indirizzo e-mail, quindi
premere il pulsante OK.
Gegebenenfalls eine E-Mail-Adresse eingeben und
dann die Taste OK drücken.
Si es preciso, introduzca una dirección de correo
electrónico y luego pulse el botón Aceptar.
Digite um endereço de e-mail, se necessário, e
pressione o botão OK.
EN
FR
IT
DE
ES
PT
Enter an Email address if required,
and then press the OK button.

Xerox Phaser 6128MFP Specifications

General

Print technology	Laser
Maximum resolution	600 x 600 DPI
Economical printing	Yes
Time to first page (black, normal)	14 s
Time to first page (color, normal)	17 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Print speed (color, normal quality, A4/US Letter)	12 ppm
Scanner type	Flatbed scanner
Image formats supported	JPG, TIF
Copier resize	- %
Time to first copy (black, normal)	18 s
Copy speed (black, normal quality, A4)	16 cpm
Copy speed (color, normal quality, A4)	12 cpm
Faxing	Mono faxing
Fax speed dialing (max numbers)	200
Total input capacity	250 sheets
Total output capacity	150 sheets
Display	LCD
Market positioning	Business
Internal memory	384 MB
Card reader integrated	No
Sound pressure level (copying)	52.2 dB
Sound pressure level (printing)	14.9 dB
Maximum print size	216 x 297 mm
Paper tray media types	Bond paper, Card stock, Envelopes, Glossy paper, Labels, Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 216 g/m²
Power supply type	AC
Dimensions (WxDxH)	425 x 507 x 585 mm
Power requirements	120 V, 50/60 Hz
Networking features	Fast Ethernet
All-in-one functions	Copy, Fax, Scan
Standard media sizes	76.2 x 127 mm - 215.6 x 355.6 mm
Color all-in-one functions	copy, print, scan
Compatible operating systems	Windows 2000+ Mac OS X v10.3 - 10.5 Red Hat Enterprise Linux 5 Desktop SUSE Linux Desktop 10+
Dimensions (W x D x H) (imperial)	16.7 x 20 x 23 \
Acoustic power emissions (active, print, copy or scan)	62.2/30.3 dB
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18.4 W
Power consumption (average operating)	360 W
Sustainability certificates	ENERGY STAR
Certification	EEC, FCC
Maximum duty cycle	40000 pages per month
Recommended duty cycle	3000 pages per month
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Non-operating relative humidity (non-condensing)	10 - 85 %
