Xerox Phaser 6700 Service Manual

9-100 Xerox Internal Use Only Phaser 6700 Printer Service Manual
Xerox Supplies and Accessories
Toner Cartridges are available in metered or regional versions. Printers are shipped
from the factory with neutral cartridges that are set for metered use at power up or
adopt the region when the first non-neutral cartridge is installed. Two regional
variants, North America / Xerox Europe (NA/XE) and Developing Markets
Operations (DMO) are available.The table lists Toner Cartridge part numbers for
metered or regional versions. Neutral appears as the cartridge type until metered
toner is enabled or a regional (NA/XE or DMO) cartridge is inserted.
Note
Toner level in the cartridge is determined by auger turns and sensors. Toner
level is set to 100% when a new cartridge is installed. Toner Cartridge life (A/
A4 pages at 5% coverage) is 12K for CMY, 18K for K for hi-cap, 15K for CMY,
21K for K for metered, and 5K for CMY, 7.1K for K for standard and neutral.
Note
Imaging Unit life is determined by number of prints, cycles (rotation time) and
pixel count (dispense time). Life is 50K pages with 4 page per job average and
< 15% coverage.
Waste Toner status is determined by a sensor for almost full and a page count
after that for full. Life should be about 25 K A/A4 pages at 5% coverage per
toner, 20% cumulative, to almost full and another 3600 pages to full.
The Maintenance Kit life is determined by page count. Life is 150K A/A4 pages
to a near end of life warning, approximately 180K A/A4 pages to end of life
error hard stop.
Toner Cartridge Types
Region/Type Description Capacity
NA/XE/DMO Cyan Standard Capacity 5,000
Magenta Standard Capacity 5,000
Yellow Standard Capacity 5,000
Black Standard Capacity 7,100
Cyan High Capacity 12,000
Magenta High Capacity 12,000
Yellow High Capacity 12,000
Black High Capacity 18,000
Metered Cyan Metered 15,000
Magenta Metered 15,000
Yellow Metered 15,000
Black Metered 21,000
www MK-Electronic de

Xerox Phaser 6700 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Time to first page (black, normal)	7 s
Time to first page (color, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum duty cycle	120000 pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Internal memory	1024 MB
Maximum internal memory	2048 MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	59 dB
Total input capacity	550 sheets
Total output capacity	500 sheets
Multi-Purpose tray input capacity	150 sheets
Maximum print size	210 x 297 mm
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels, Plain paper, Pre-Printed, Recycled paper, Transparencies
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A4
Multi-purpose tray media types	Letterhead
Standard interfaces	Ethernet, USB 1.1, USB 2.0
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Current rating	12 A
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	118 W
Power consumption (printing)	672 W
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	CE, FCC Part 15, Class A, GOST, UL
Product color	White
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Authentication method	HTTPS, IP filtering, IPPS, IPSec, IPv6, SMTP, SNMPv3, SSLv3

Weight and Dimensions

Dimensions (WxDxH)	560 x 516 x 429 mm
