Phaser 6700 Printer Service Manual Xerox Internal Use Only 9-13
Part List 3.1 Feeder/Registration Assembly (1/3)
Item Description Part Number
1 Switch Assy Size (Size Switch) 110K15830
2 Holder Assy Sensor Low (with 3,4) 019K10650
3 Holder Sensor
4 Sensor Photo (Low Paper Sensor 1 and 2) 930W00123
5 Block Release 014E64090
6 Guide Tray
7 Tray 1 Separator Assy (with 9~12) 054K42171
8 Holder Assy Separator MSI
9 Holder Spring Separator
10 Spring Separator MSI
11 Bracket Separator
12 Chute Base Separator
13 Cover Guide Harness
14 Guide Harness
99 Kit Tray 1 Separator Roller (with 8) 604K65040
To Next Page
