Xerox Phaser 6700 Service Manual

Phaser 6700 Printer Service Manual Xerox Internal Use Only 9-17
Part List 3.3 Feeder/Registration Assembly (3/3)
Item Description Part Number
1 Chute Assy Regi (With 2-23)
2 Cover Spring Rear
3 Cover Spring Front
4 Chute Assy Upper Regi
5 Spring Chute Upper
6 Bracket Nip
7 Spring Regi R
8 Spring Regi F
9 Roll Regi Metal
10 Roll Assy Regi Rubber
11 Roll Assy Take Away
12 Clutch Assy Take Away (Take Away Clutch) 121K43551
13 Clutch Assy Regi (Registration Clutch) 121K43541
14 Bearing Regi
15 Bearing Regi Earth
16 Clamp Locking
17 Chute Regi
18 Gear Regi Metal
19 Gear Regi Rubber
20 Actuator Regi SNR (Registration Sensor Actuator) 120E31603
21 Spring Sensor Regi
22 Sensor Photo (Registration Sensor) 930W00123
23 Harness Assy Regi SNR (J105-J203)
