Phaser 6700 Printer Service Manual Xerox Internal Use Only 9-19
Parts List 4.1 Right Cover and Frame
Item Description Part Number
1 Harness Assy I/L RH (I/L SW-J301)
2 Cover Intlk
3 Cover Connector
4 Bracket Assy Pivot Front
5 Spring RH Frame
6 Bracket Assy Pivot Rear
7 Chute Dup RH
8 Fuser Fan 127E85810
9 Guide Harness RH Fan
10 Guide Slide Latch
11 Link Assy
12 Guide Support Link
13 Guide Plate Latch
14 Latch Cover RH
15 - -
16 Spring Latch Cover
17 Guide Fuser RH 032E32010
18 Holder Intlk RH
19 Actuator Intlk RH
20 Spring Intlk RH
21 Strap RH (Right Door Stopper Strap) 868E26010
22 Cover RH
23
24 Spring Stopper MSI
25 Stopper MSI
26 Cover Assy MSI (with 27, 28)
27 Cover MSI
28 Tray Assy MSI
29 - -
30 Shaft Pivot
31 Cover Assy RH (with 7~14,16~22, 24, 25)
96 Kit Interlock Switch RH (with 1, screw driver) 604K57040
97 Kit Actuator Intlk RH (with 18-20) (Right Door
Interlock Actuator)
604K56450
98 Kit Cover Assy Tray 1 (with 26) 604K64951
99 Kit RH Cover & Frame Assy (with 4~6, 30~31, PL4.2,
PL4.3, PL4.4.2~14)
604K64966
