Phaser 6700 Printer Service Manual Xerox Internal Use Only 9-41
Parts List 8.1 Frame (1/2)
Item Description Part Number
1 Guide Assy CRU (Imaging Unit Guide) 032K05793
2 - -
3 - -
4 - -
5 - -
6 - -
7 - -
8 - -
9 Frame Assy 2nd (Inner Frame Assy) 801K44481
10 Guide Harness OP Panel
11 Clamp Locking
12 - -
13 Guide Frame Lock H
14 Guide Frame Lock V
15 Shaft Pivot Frame 2nd 806E28030
16 Cover FR Under
17 Foot
18 Bush
19 Guide Air Trans
20 Clamp Locking
21 Bush Close-type
22 Foot Rubber
99 Kit Foot Assy (with17x4 pcs, 22x4 pcs) 604K64990
