Xerox Phaser 6700 Service Manual

Phaser 6700 Printer Service Manual Xerox Internal Use Only 9-49
Parts List 10.1 Electrical (1/2)
Item Description Part Number
1 Box Assy ESS PWB (with 4, 5, 26, 28) (IP Cage)
2 Plate Window ESS
3 Screw Knurling
4 Box Assy Base
5 Image Processor Board (with rear panel, No NVRAM,
No SD Card, No RAM) (with 6, 7, 29)
960K65211
6
7
8
9 LVPS Fan Assy (with 10, 11) 101K58770
10 LVPS Fan
11 Plate LVPS Fan
12 Plate Assy LVPS Power (with 13-18) (Power Panel) 101K58761
13 Plate LVPS Power
14 Harness Assy Fin Pwr (OUTLET-J311,T171)
15 Breaker GFI Inlet
16 Wire Assy GFI Earth (J175-T170)
17 Clamp Locking
18 Harness Assy AC (J300-J173,J174)
19 Power Cord Refer to “Power
Cords” on
page 9-101.
20 - -
21 - -
22 PWBA EEPROM (EEPROM Board) 960K47800
23 Hard Drive 121K51060
24 RAM Memory 1GB
RAM Memory 2GB
237E25730
237E26060
25 SD Card (with system software) 237E26720
26 Clamp Locking
27 Clamp Press Rec-16
28 - -
29 Support
30
31
32 Support
33
34 Clamp
35 Clamp
36 NVRAM (IP Board NVRAM IC) 960K66600
37 Cover Rear ESS
www MK-Electronic de

Xerox Phaser 6700 Specifications

General

Color	Yes
Duplex printing	No
Print technology	Laser
Maximum resolution	1200 x 2400 DPI
Time to first page (black, normal)	7 s
Time to first page (color, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Wi-Fi	-
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum duty cycle	120000 pages per month
Page description languages	PCL 5e, PCL 6, PostScript 3
Internal memory	1024 MB
Maximum internal memory	2048 MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	59 dB
Total input capacity	550 sheets
Total output capacity	500 sheets
Multi-Purpose tray input capacity	150 sheets
Maximum print size	210 x 297 mm
Paper tray media types	Card stock, Envelopes, Glossy paper, Labels, Plain paper, Pre-Printed, Recycled paper, Transparencies
Paper tray media weight	60 - 220 g/m²
ISO A-series sizes (A0...A9)	A4
Multi-purpose tray media types	Letterhead
Standard interfaces	Ethernet, USB 1.1, USB 2.0
USB 2.0 ports quantity	1
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion
Other operating systems supported	Novell NetWare 5.x, Novell NetWare 6.x, Novell Open Enterprise Server
Server operating systems supported	Windows Server 2003, Windows Server 2008
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Current rating	12 A
AC input voltage	220 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	118 W
Power consumption (printing)	672 W
Sustainability certificates	ENERGY STAR
Display	LCD
Certification	CE, FCC Part 15, Class A, GOST, UL
Product color	White
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Operating relative humidity (H-H)	10 - 85 %
Networking features	Gigabit Ethernet
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Authentication method	HTTPS, IP filtering, IPPS, IPSec, IPv6, SMTP, SNMPv3, SSLv3

Weight and Dimensions

Dimensions (WxDxH)	560 x 516 x 429 mm
