Phaser 6700 Printer Service Manual Xerox Internal Use Only 9-55
Parts List 11.2 Harnesses (2/2)
Item Description Part Number
1 Harness Assy Erase/Exit (J16,J17-J106, J108, J215,
J228, J229, J230, J231)
962K78800
2 Harness Assy ROS/HV (J3, J13, PL1.3.6 Rear I/L SW,
J151, J153, J144, J303, J702)
962K74580
3 Harness Assy RH/MOT (J7,J9-P100, P117, P118, P120,
J200, J254, J255)
962K74590
4 Harness Assy CRUM/DISP (J12,J15-J201, J208, J209,
J210, J211, J259)
962K74600
5 Harness Assy LPP/MOT (J5,J6,J18,J21-DP181, J219,
J221, J222, J252, J253, J260, J307, J315)
962K74610
6 Harness Assy DISP/FSR (J4,J19-P122, J250, J251,
J256, J257, J258)
962K77370
To Next Page
