Phaser 6700 Printer Service Manual Xerox Internal Use Only 9-57
Part List 12.1 550-Sheet Feeder (1/5)
Item Description Part Number
1 550 Option Feeder (with 2, PL12.5.1, instructions) 059K77370
2 Feeder Assy 550 (with 4, 7, 13~18,PL12.2~PL12.4)
3 Screw Lock
4 Cover Rear
5 Plate Lock Rear Assy
6 Screw Lock Rear
7 Chute Upper Assy (with 8~12) 054K39101
8 Roll Pinch Ta
9 Spring Pinch Ta
10 Chute Upper Top
11 Chute Upper
12 Plate Magnet
13 Arm Chute
14 Cover RH Opt (right side door)
15 Chute Under
16 Cover Right
17 Cover Front
18 Cover Left
99 Optional Feeder Mounting Kit (with 3x2pcs, 5, 6) 604K65010
To Next Page
