Phaser 6700 Printer Service Manual Xerox Internal Use Only 9-67
Parts List 13.1 1100-Sheet Feeder
Item Description Part Number
1 1100 Option Feeder (with 2, 10-12) 059K77380
2 Feeder Assy 1100 (with 3~9,11~14, PL13.2.1x2pcs,
PL13.6.1x2pcs)
3 Cover Rear C
4 Cover Right C
5 Cover Front C
6 Cover Left C
7 Caster Front 417W41349
8 Caster Rear 417W41449
9 Foot 017E12741
10 Screw Lock
11 Plate Lock Rear Assy
12 Screw Lock Rear
13 Plate Lock Opt F
14 Frame Assy Caster
99 Optional Feeder Mounting Kit (with 10x2, 11-12) 604K65010
To Next Page
