Phaser 6700 Printer Service Manual Xerox Internal Use Only 9-69
Parts List 13.2 Covers
Item Description Part Number
1 Feeder Assy 550 (with 2, 5, 11~16, PL13.3~PL13.5)
2 Cover Rear
3 - -
4 - -
5 Chute Upper Assy (with 6~10) 054K39101
6 Roll Pinch TA
7 Spring Pinch TA
8 Chute Upper Top
9 Chute Upper
10 Plate Magnet
11 Arm Chute
12 Cover RH Opt
13 Chute Under
14 Cover Right
15 Cover Front
16 Cover Left
