Clearing Paper Jams
Phaser® 8560/8860 Printer
6-13
3. Verify that the paper is loaded correctly in the tray. Adjust the length and width tray
guides:
a. Length guide: Press the sides, then slide the guide until the arrow on the guide points
to the appropriate paper size imprinted on the bottom of the tray. When properly
positioned, the guide clicks into place.
b. Width guides: Slide the width guides until the arrows on the guides point to the
appropriate paper size labeled on the bottom of the tray. When properly positioned,
the guides click into place.
Note: When the paper guides are correctly adjusted, there may be a small space between
the paper and the guides.
8860p-107
8860p-108
